Overshot Assembly NQ
Certification: ISO9001
Minimum Order Quantity: N/A
Price: Negotiation
Packaging Details: Steel Belt Iron Frame Export Wooden Case
Delivery Time: 10-15 working days after payment
Payment Terms: T/T or L/C
Supply Ability: 10,000pcs per month
Description
Product Name: |
NQ Overshot Assembly For Wireline Coring Drilling |
Standard: |
DCDMA |
Avalilable Size: |
BQ NQ HQ And PQ |
Application: |
Overshot Assembly Is A Kind Of Tool Specially Used To Salvage And Place Inner Tube Assembly. At Present, We Have Four Kinds Of Q Series Overshot Assembly: BQ, NQ, HQ And PQ |
HQ Wire Line Overshot Assembly Core Drilling Tools Machining Casting
Detail
The Q series overshot assembly is a kind of tool specially used to salvage and place inner tube assembly. At present, we have four kinds of Q series overshot assembly: BQ, NQ, HQ and PQ.
Its main components are salvage frame and salvage hook. Regarding those to be exported, the Q series overshot assembly will be packed by export-standard plywood boxes.
Its compact structure enables it to avoid accidental release of core barrel, and it is quite suitable for surface applications.
Specification:
Available size
International Standard:BQ NQ HQ PQ
Chinese Standard: Wireline 56, wireline 59, wireline 75, wireline 95
 |
 |
Technical Parameters:
| Model | Overshot assembly | ||
| Length(mm) | Outer diameter (mm) | Unit weight(kg) | |
| BQ | 1550 | 42 | 25 |
| NQ | 1903 | 51.5 | 28 |
| HQ | 1903 | 51.5 | 32 |
| PQ | 1903 | 61 | 35 |
Our Services
Delivery Time: Based on order quantity, normally it takes 10-15 days .
Quality Control: We have our professional QC and all the products will be strict inspection and testing for every order before shipping out.
After Services: Technical Support will be available in any time. We could provide the professional suggestion for you.
